Sample Mapping Station Layout - Format Romeo 9 Mapping.
Station has radio with o/s antenna on Primary Net Frequency to
report to NCS.
This Station is Mapping a sample Fire,
plotting its location, wind speed and direction at fire
location, and distance to Shingletown Areas.
The larger Area Map is being used in this
illustration. Photo
(smaller)
(larger) |
